Fully Automated System
Automatic satellite search and identification. 2-axis step motors to stabilize the pedestal.
Enhanced Antenna
Highly efficient 34 inch parabolic antenna enables 44dBW of minimum EIRP. RHCP / LHCP, Vertical / Horizontal polarization.
Wide Range Search (WRS) Algorithm
Competitor methods search for the narrow-bandwidth of the main lobe. However Intellian’s exclusive WRS searches for the wide range of side lobes and jumps up to the main lobe, providing faster satellite acquisition.
Fully Automated Digital Video Broadcasting (DVB)
Identification DVB Decoder with CPLD enables high speed identification.
Dynamic Beam Tilting (DBT) Technology
A high-speed sub-reflector rotates off axis, checking signal strength at 50 times per second and compensating the tracking direction. Less movement of the main-reflector means less noise and extends the product life.
DVB-S2 Signal Identification
High speed identification employing DVB-S2 Decoder.
New Type Antenna Control Unit
• Easy to change and update satellite information
• Easy antenna status check and automatic diagnosis
• Easy antenna control using PC interface
Automatic Polarization (Skew-angle) Control
Automatic Skew Angle Control System (-90°~ +90°) for Linear Horizontal / Vertical Polarization.
Built-in GPS and NMEA 0183 Interface Port
The i9P includes a built-in GPS inside of the Antenna Unit for faster signal acquisition. The ship’s GPS can also be connected through the NMEA 0183 port on the rear panel of the ACU.
